TV System

NTSC

Pick Up Device

1/3” Sony Color Ccd Image Sensor

Picture Elements

768 H X 494 V

Horizontal Resolution

480 Lines

Mini Illumination

0.1 Lux

Horiz. Sync.Frequency

15.734 Khz

Vertical Frequency

60 Hz

Clock Frequency

19.0699 Mhz

Scanning System

2:1 Interlace

White Balance

Auto Trace Mode

Signal To Noise Ratio

48 Db (Agc Off) Over

Electronic Shutter.

1/60~1/100,000 Sec

Lens

3.6 Mm / F 2.0

Video Output

1 V P-P, 75 Ohms

Gamma. Correction

0.45

Dimensions D×L

F 26×89

Weight G.

170

Power Supply

12vdc (+/-0.5)

Power Consumption

150ma

Storage Temperature

– 30 To +60

Operating Temperature

– 20 To +55
