Power	115 Volts, 1 Phase
Frequency	50-60 Hz
Available Horse Power	1/2 HP
Maximun Gate Weight	1500 lbs
Maximun Cycles per Hour	35
Maximun Gate Width	25 feet
Gate Speed	13 seconds from open to close 90º
Class 2 Low Voltage Control Circuit
U/L 325 Listed for use in Class I through IV
Weight	220 lbs





• Solid state control board with diagnostic LEDs to indicate all input and output functions.
• External control, input terminal connections for:
• Radio Receivers
• Push Button Control Station
• Key Switches
• Loop Detectors
• Card Key Readers
• Telephone Entry Systems, etc.
• Timer to close with 0-60 sec. adjustment standard. Longer timer available upon request.
• Maximum run timer for equipment protection (self adjusting)
• Master/Slave option with dedicated terminal connection provided.
• Easy Left/Right changeover.
• Time delay on reverse to ensure smooth gate motion and less stress on equipment.
• Spike suppressing circuitry for surge and lightning protection.
• Emergency control enabling circuitry for safety with security.
• Electrical dynamic brake for precise gate positioning.
• Magnetic gate lock control circuitry with 115 Volts output terminal.
• Integral current sensing, anti-entrapment circuitry with independent opening and closing sensitivity adjustments.
• External anti-entrapment circuitry with separate terminal connections for easy installation of contact and non-contact sensors.
• ½ HP, 115 Volts AC, 6 Amp., 1 phase, instant reversing, switchless, PSC motor, with thermal overload protection, high speed ball bearing and resilient mount for smooth, quiet operation.
• Internal ON/OFF power switch.
• Two grounded 115 Volts AC, 15 Amp. Convenience receptacles.
• NEMA 1 one-button control station included.



• Heavy duty #11 Ga. Galvanized steel frame providing a strong and durable unit.
• #16 Gauge galvanized steel, lockable exterior cover for drip proof water protection.
• Hard shell, baked-on weather resistant powder coating, with an attractive textured finish, for years of aesthetic protection from the elements.
• Timing belt primary reduction for smooth, quiet and positive operation.
• Heavy Duty 45:1 oil bath type gear reducer for long service and dependable operation.
• Heavy Duty #40 sprocket and roller chain arrangement for final drive reduction.
• Heavy Duty pillow block type ball bearing supporting output drive shaft and enabling extended endurance under heavy loads with low maintenance.
• Drive arm easily disconnected for manual operation in case of power failure.
• Easy adjustable limit switch cams for precision gate positioning.
• Soft start and stop at open and close limits of travel, due to the inherent geometry of the articulating drive arm linkage.
• Pad mounted for a strong, solid installation.
